Name: SuperEko PU
Brand: Nuhpanel
SKU: NRP3EE-SE

SuperEko PU

SuperEko PU is the thinnest section in the EXO range: a seven-rib profile with thicknesses between 10 and 30 mm.

This section is below the thicknesses normally used in sandwich roof panels and serves more as a covering than as insulation. The intended application should be confirmed with the technical team. The core is polyurethane: 0.022 W/mK thermal conductivity, B-s2-d0 fire class.

The surface facing is polyester; this product also has a PE option. Panel length is up to 12 metres. Where insulation genuinely matters, standard thicknesses are used; a comparison is on the EXO panels page.

How much panel is needed

Enter the dimensions of the surface to be covered.

Width to cover m Panels are laid side by side across this width Panel length m Each panel is cut to this length

The result is an estimate. The exact count follows the roof geometry, eaves allowances and the cutting plan.

Technical properties

Product code	NRP3EE-SE
Design	7 Rib
Cover width	1000 mm
Maximum length	12
Core	PU
Thickness	10 / 15 / 20 / 30 mm
Coating	Polyester, PE
Thermal conductivity	0.022 W/mK
Fire class	B-s2-d0
Density	36-45 kg/m³ PIR

Fire class: Sınıf PUR çekirdek içindir. Aynı panel PIR çekirdekle B-s1-d0'dır.
